Info Help

NAVIGATION: Info Help

"Online Help, Devices"

No. 0842.26B.1-00

Date: January 2013

This document details the functionality of the following device and firmware variants:

Single-axis system SO8x.xxx0.xxxx.xxxx.x / from firmware version V3.25-00
Multi-axis system SO8x.xxx1.xxx.xxx.x / from firmware version V3.25-00
Junior SO2x.xxx0.xxxx.xxxx.x / from firmware version V1.30-00

Subject to technical change without notice.

The content of this Application Manual was compiled with the greatest care and attention, and based on the latest information available to us. We should nevertheless point out that this document cannot always be updated in line with ongoing technical developments in our products. Information and specifications may be subject to change at any time.

www.lt-i.com

Available documents at a glance

Document	Contents	Description
Operation Manual	Mechanical installation, Electrical installation, Safety, Specification	Hardware
Online device help (also as PDF)	Basic software description	Accessible in DriveManager 5
Online program help (also as PDF)	DriveManager 5 Description	Accessible in DriveManager 5
CANopen/EtherCAT User Manual	Description of CANopen/ EtherCAT field bus system	Hardware and software of field bus version
SERCOS User Manual	Description of SERCOS II field bus system	Hardware and software of field bus version
PROFIBUS-DPV User Manual	Description and parameter-setting of the ServoOne on the Profibus-DPV field bus system	Hardware and software of field bus version

Tabelle: Overview of documents

How do I read the documentation?

First be sure to read the Operation Manual, so as to install the device correctly. The layout of the sections of this Application Manual and the order of subject areas in the DriveManager follow the chronological sequence of an initial commissioning procedure. For basic configuration and operation of the motor you should follow the descriptions in the sections of this Application Manual. If you intend to utilize further internal functions of the drive, such as digital or analog I/Os, you should read the corresponding sections in this documentation. Here you will also find information concerning errors and warnings. If you use a field bus option board to control a controller, please use the relevant separate bus documentation.

ATTENTION:

Disregarding the safety instructions during installation may pose a danger to life for operating personnel and result in destruction of the output system.

Pictograms

To provide clear guidance, this Application Manual uses pictograms. Their meanings are set out in the following table. The pictograms always have the same meanings, even where they are placed without text, such as next to a connection diagram.

Pictograms	Meaning
	NOTE: Useful information
	ATTENTION: Misoperation may result in damage to the drive or malfunctions.
	DANGER from electrical tension! Improper behaviour may endanger human life.
	DANGER from rotating parts: The drive may execute uncontrolled movements!

Tabelle: Meanings of pictograms

Legal notice

LTi DRiVES GmbH provides the information and subject area listings contained in the Online Help as a service.LTi DRiVES GmbH gives no guarantee that the information provided will achieve the desired results in your specific application environment.
The decision as to whether to use the information provided – and if so, in what form – is entirely yours.
The specialist personnel must ensure that the application or usage of the products described conforms to the technical specifications set out in the Installation Guide and the Operation Manual, as well complying with all safety requirements, including applicable laws, rules, regulations and standards.
The Help was compiled with due diligence. However, the products described are continually being developed and improved. Consequently, the Help may not always be fully verified as conforming to the functionality, standards or other features specified.
The statements made in this document do not embody a guarantee under the terms of Article 443 of the German Civil Code (BGB) or a specification of contractually required usage under the terms of Article 434 paragraph 1, clause 1, no. 1 BGB.
If the Help contains any factual or typographical errors, we reserve the right to make changes at any time and without prior notice.
The content of this Help is provided merely for information purposes. It may be changed without prior notice at any time, and in no way imposes any obligation upon LTi DRiVES GmbH.
The information, illustrations and descriptions contained in this document cannot be used as justifiable grounds for modification of already delivered products.

copy; The Help is protected by copyright. It must not be disclosed or distributed, or used by third parties, in whole or in part, without the written consent of LTi DRiVES GmbH.
